Instantaneous water heater for showers
WS 45 E-2 (STE)

    • Temperature adjustment via stepless power control
    • Complete set optimised for a single shower
    • Corrosion-free copper heating element for longer service life
    • 5-in-1 shower head with slide bar for convenient height adjustment
    • Anti-scalding and overheating protection with double action thermostat
    • Protection from electric shock with Earth Leakage Sensing Device (ELSD)
    • Protection class IP25 (splash-proof)
    Questions about the product Get contact

    Product details

    APPLICATION: Electric instantaneous water heater with shower head set – the complete solution for single showers. Domestic hot water is provided instantly at the shower, without waiting.

    EQUIPMENT & CONVENIENCE: Shower unit featuring steplessly adjustable power control up to the rated maximum power. The shower head features 5 different spray settings ranging from gentle to massage and is mounted on a slide bar for convenient height adjustment.

    INSTALLATION: Quick and easy installation. Drilling template provided. Splash-proof.

    EFFICIENCY: Highest energy efficiency rating – “Electricity Saving Label No. 5”.

    SAFETY & QUALITY: Highest electrical safety certified to international standards guarantees trouble-free operation. The Earth Leakage Sensing Device (ELSD) detects any harmful leakage current and shuts off the power supply, thereby providing full protection from electric shock. Anti-scalding protection with integrated thermal cut-out to limit the water outlet temperature. The flame-retardant electronic circuit board and pressure-resistant copper tank provide additional safety and durability. The heating element is made from corrosion-resistant copper for superior durability and maintenance-free operation, even in chlorinated water.


    Technical datasheet

    Product Number: 203186

    Electrical fuse protection: ELSD

    Rated output: 4,500 W

    Electrical connection: 1/N/PE~220-240 V

    Display: Standard

    Heating element: Copper tubular

    Type: Open outlet

    Automatic flow switch: true

    Heating material: Copper

    Temperature setting: Variable

    Temperature control: Output control

    Anti-scalding protection: Double acting thermostat

    Shower accessories: 5-in-1 head shower with slide bar

    Colour: white

    IP rating: IP 25

    Depth: 79 mm

    Height: 326 mm

    Width: 200 mm

    Weight: 1.4 kg

    Show all

    Download as PDF

Installation Information:

Please ask your local power supply utility or a registered electrician to install appliances that are not fully wired, i.e. ready to plug in. The electrician should also be able to assist you with obtaining the agreement of the respective power supply utility required for the appliance installation.
